A solar inverter carries out the vital task of regulating the flow of current in the solar system and converting the direct current (DC) into alternating current (AC).
Selecting a suitable solar inverter depends on factors such as the technology used to make the inverter, efficiency, availability, the size of the solar system, etc.
In this particular guide, we will be specifically talking about a 1 kVA solar inverter: the 1kva solar inverter with battery price, the types, advantages, and more.
If you’ve been meaning to find out the 1kva solar inverter with battery price, this guide is a goldmine of answers. Dive in for details.
How Does a Solar Inverter Work?
Yes, we said that we’ll be talking about the 1kva solar inverter with battery price, but first things first – how does a solar inverter work?
It’s simple.
DC electricity from the panels is supplied to the solar inverter. Most solar inverters, nowadays, have an inbuilt charge controller.
In the case of a grid-tied inverter, DC electricity is converted into AC electricity and supplied to the load. The inverter passes the excessive units of electricity to the grid through a bi-directional metre.
In the case of an off-grid solar system, excessive units from solar panels are used to charge the batteries.
During voltage fluctuations, on-grid solar inverters regulate the energy output and shut down in case of an electrical arc to protect the system from damage.
When talking about a 1kva solar inverter with battery price, it’s either an off-grid system or a hybrid system that the inverter is being used for since batteries are used in just these two, not on-grid systems.
That being said, for all three types, without a solar inverter, a solar system is an impractical model.
Different Types of 1 kVA Solar Inverters
There are three main solar inverters – string inverters, micro-inverters, and SolarEdge Optimiser.
String Inverters: These are connected to the solar array and used for domestic and grid-connected commercial solar plants.
Micro Inverters: Individual micro-inverters are connected directly to individual solar panels. Micro inverters are costlier than string inverters as they offer higher efficiency.
SolarEdge Optimiser: This DC/DC converter directly connects to each solar module and turns them into smart modules, optimising efficiency. It’s a patent of the SolarEdge company. It continuously monitors the maximum power production of each panel to enhance energy generation and efficiency; thereby, growing the revenue and shortening the break-even period.
The Technology Used by 1 kVA Solar Inverters
1 kVA solar inverters use the Maximum Power Point Tracking (MPPT) Inverter Technology; as such, they are called MPPT solar inverters. They provide maximum efficiency, ranging from 95% to 97%, and are considered the best solar inverters in the market.
PWM technology is now obsolete as all inverters use MPPT for higher efficiency. The 1kva solar inverter with battery price will also be slightly higher when MPPT technology is embedded.
Moving on, let’s discuss the details of a 1kVA solar inverter before finally delving into the 1kva solar inverter with battery price.
1 kVA Solar inverter: Features
Here are the most relevant features you should be aware of as a customer.
These inverters:
- Do not require transformers
- Have a maximum efficiency of over 98.3%
- Have an ultra-wide input voltage range that reduces voltage surge and overload
- Might have a dual MPPT technology running on a highly accurate MPPT algorithm
- Have a compact and light-weight design
- Might have an advanced RS 485 interface, with WiFi/GPRS options available
- Have a monitoring app available for easy usage
- Have multiple safety levels for fire protection
- Have a standard warranty of 5 years; extendable up to 10 years
To understand more about the 1kva solar inverter with battery price, let’s look at some specifications.
Product specifications of a 1 kVA Solar Inverter
A wide range of battery support is available, including 12V, 24V, 48V, and so on. 1 kVA solar inverters protect your solar system from short-circuit, output over-voltage, and power surges.
They do so by:
- Monitoring the grid and insulation resistance
- Detecting temperature variations
- Reversing DC polarity if required
1 kVA Solar Inverter: Technical Specifications
Specifications usually differ from brand to brand; thus, 1kva solar inverter with battery price will vary accordingly. The technical specifications are as follows:
INPUT ASPECTS
- Maximum Input Voltage (V) – 450V
- Maximum Input DC Voltage Range (V) – 50-400
- Maximum Input Power (kW) – 1.2
- Startup Input Voltage (V) – 60
- Maximum Input Current (A) – 10
- MPPT Number or Number of Strings per MPPT – 1,1
OUTPUT ASPECTS
- AC Grid Voltage Range (V) – 180-270 (Adjustable)
- Rated Output Power (kW) – 1
- Rated Grid Frequency (Hz) – 50
- Rated AC Grid Voltage (V) – 220/230/240
- Operating Phase – Single Phase
- Output Power Factor – >0.99
- Grid Current THD – < 3%
- Nominal AC Output Current (A) – 4.3
- Maximum AC Output Current (A) – 6.1
- DC Injection Current (mA) – < 20
- Operating Frequency Range (Hz) – 47-52
EFFICIENCY ASPECTS
- Maximum efficiency – 96.7%
- Euro efficiency – 96.2%
- MPPT efficiency – >99.50%
1 kVA solar inverter with battery price in India
Finally, we are holding the snake by its tail: what is the 1kva solar inverter with battery price in India?
A 1kva solar inverter with battery price will vary from brand to brand. In India, the 1kva solar inverter with battery price ranges between ₹16,000 to ₹17,500.
1 kVA Solar Inverter VS Normal Inverter
The 1kva solar inverter with battery price differs from a normal inverter price as there are significant differences between the two.
Let’s find out more!
- A 1 kVA solar inverter can function with or without a battery, while a regular inverter cannot function without a battery.
- A 1 kVA solar inverter battery can be charged via the grid and solar electricity. A normal inverter can be charged only via grid electricity.
- A normal inverter is only used for domestic purposes, but a 1 kVA solar inverter is used for commercial and domestic purposes.
Advantages and Uses
A 1 kVA on-grid solar inverter has many uses and advantages. They include
- Minimum space requirement: It is great for installation in small spaces.
- No load restrictions: It does not have a load restriction. On-grid inverters export any extra energy to the grid.
Here is one additional use of a 1 kVA solar inverter in an off-grid or hybrid solar system:
- Energy storage: Stores the extra energy in the solar battery.
Conclusion
Your solar system cannot function without a solar inverter; thus, buying one is a necessity, not an option. Now you also know the solar inverter 1kva price and its features and specifications.
So, with the right brand, you can rest assured that the solar inverter 1kva price will prove to be beneficial and cost-effective in the long run.
FAQs
1. What factors should I consider while investigating the 1kva solar inverter with battery price?
You should pay close attention to the kind of technology used, warranty period, and capacity of your solar system.
2. What is the technology used in a 1 kVA solar inverter?
MPPT inverters are the most prefered choices nowadays. They consistently track the maximum power generated; thereby, increasing the output.
3. How many modules should I install with the 1 kVA solar inverter?
Use this simple calculation to find out how many modules you need to install:
Divide the total wattage required by the wattage of the module you have.
For example,
If you have a 350 Wp module at hand with a total wattage requirement of 1000 watts, here’s what the calculation would look like:
1000/350 = 2.85
Thus, you require about 3 modules.
